Fast conversion of 2D arrays to [x, y, value] triples with NumPy meshgrid or Pandas stack

Convert a 2D array into [x, y, value] triples without slow loops: use NumPy meshgrid+hstack or Pandas stack+reset_index for fast, scalable Python processing.

Transforming a 2D image array into a compact list of [x, y, value] triples is a common task in data processing, visualization, and feature extraction. The straightforward approach with nested loops tends to be painfully slow on large arrays, even when the logic is correct. Below is a concise walkthrough of why this happens and how to do the same job efficiently with NumPy or Pandas.

Problem setup

Assume we start with a 1000×1000 image-like array and want a three-column matrix where the first two columns are the x and y coordinates and the third column is the pixel value from the original array.

Naive implementation that hits performance limits

import numpy as np
arr2d = np.random.rand(1000, 1000)
pts = np.array([(cx, cy) for cx in range(arr2d.shape[1]) for cy in range(arr2d.shape[0])])
pts = np.c_[pts, np.zeros(pts.shape[0])]
for r in range(arr2d.shape[0]):
    for c in range(arr2d.shape[1]):
        pts[np.logical_and(pts[:, 1] == r, pts[:, 0] == c), 2] = arr2d[r, c]

The logic above is straightforward: prebuild all coordinate pairs, then walk the image and fill in the value at the matching position. In practice, it is super slow on large inputs, because the coordinate selection and assignment run inside nested loops over the entire array.

What’s going on

The approach repeatedly scans and matches coordinates for each element in the array, which leads to a heavy amount of work. The resulting output is correct in theory, but the runtime becomes impractical for arrays with hundreds of thousands or millions of elements. The goal is to produce the same [x, y, value] structure without iterating in Python.

Efficient solutions

There are two succinct ways to achieve the same result. One uses Pandas to reshape the data in a few steps. The other stays purely in NumPy and constructs coordinate grids directly.

Option 1: Pandas stack + reset_index

import numpy as np
import pandas as pd
arr2d = np.random.rand(1000, 1000)
result = pd.DataFrame(arr2d).stack().reset_index().to_numpy()

Here, DataFrame rows are the y-coordinates and columns are the x-coordinates. The stack operation folds all columns into a single column while turning x into part of a hierarchical index alongside y. The reset_index step flattens that multi-level index into regular columns, producing a structure with columns [y, x, val]. Finally, to_numpy converts it into a NumPy array.

Option 2: Pure NumPy with meshgrid + hstack

import numpy as np
arr2d = np.random.rand(1000, 1000)
rows, cols = arr2d.shape
yy, xx = np.meshgrid(np.arange(cols), np.arange(rows))
output = np.hstack([
    xx.reshape(-1, 1),
    yy.reshape(-1, 1),
    arr2d.reshape(-1, 1)
])

This builds coordinate matrices in one shot. The reshape calls convert them to column vectors, and hstack concatenates them horizontally to produce a three-column array of [x, y, value].

Why this matters

When data grows, elementwise Python loops stop being viable. Vectorized reshaping with stack or meshgrid keeps the logic simple and the code compact, while avoiding the per-element overhead that overwhelms the naive approach.

Takeaways

If you need to convert a 2D array into [x, y, value] triples, avoid nested loops and repeated coordinate matching. Use either Pandas stack with reset_index to get [y, x, val] as a NumPy array, or construct x and y grids in NumPy with meshgrid and join them with the values. Both approaches express the transformation clearly and scale much better in practice.
